Number of Headphone Channels
2-Channel
Recommended Headphone Impedance
Not Specified by Manufacturer
Headphone Output Power
4.4 mm Balanced:
650 mW into 600 Ohms
5551 mW into 32 Ohms
1/4" Unbalanced:
184 mW into 600 Ohms
2832 mW into 32 Ohms
Show Less
Analog Audio I/O
1x 1/8" / 3.5 mm TRS Unbalanced Stereo Line Input (1 Stereo Pair, Rear Panel)
2x XLR 3-Pin Balanced Mono Line Output (1 Stereo Pair, Rear Panel)
1x Stereo RCA TS Unbalanced Stereo Line Output (1 Stereo Pair, Rear Panel)
1x 1/4" TRS Unbalanced Stereo Headphone Output (Front Panel)
1x 4.4 mm TRRRS Balanced Stereo Headphone Output (Front Panel)
Show Less
Digital Audio I/O
1x RCA Coaxial S/PDIF Input
1x TOSLINK Optical S/PDIF Input
USB I/O
1x USB-B 3.0 / 3.1/3.2 Gen 1 (Digital Input)
Wireless
Bluetooth 5.4
Power Requirements
AC/DC Power Adapter (Included)
Number of Headphone Channels
2-Channel
Recommended Headphone Impedance
Not Specified by Manufacturer
Headphone Output Power
4.4 mm Balanced:
650 mW into 600 Ohms
5551 mW into 32 Ohms
1/4" Unbalanced:
184 mW into 600 Ohms
2832 mW into 32 Ohms
Digital Chipset
DAC:
1 x Burr-Brown True Native
Bluetooth:
1 x Qualcomm QCC518x
EQ
No
Display
1x Color LCD
Connectivity
Analog Audio I/O
1x 1/8" / 3.5 mm TRS Unbalanced Stereo Line Input (1 Stereo Pair, Rear Panel)
2x XLR 3-Pin Balanced Mono Line Output (1 Stereo Pair, Rear Panel)
1x Stereo RCA TS Unbalanced Stereo Line Output (1 Stereo Pair, Rear Panel)
1x 1/4" TRS Unbalanced Stereo Headphone Output (Front Panel)
1x 4.4 mm TRRRS Balanced Stereo Headphone Output (Front Panel)
Digital Audio I/O
1x RCA Coaxial S/PDIF Input
1x TOSLINK Optical S/PDIF Input
USB I/O
1x USB-B 3.0 / 3.1/3.2 Gen 1 (Digital Input)
Sync I/O
1x BNC Clock Input
Wireless
Bluetooth 5.4
Bluetooth
5.4
Supported Audio Codecs
AAC, aptX, aptX Adaptive, LDAC, LHDC, SBC
Performance
Maximum Output Level
4.4 mm Balanced Headphone:
3.5 V (12- to 600-Ohm Load)
1/4" Headphone:
4.5 V (12- to 600-Ohm Load)
XLR Line:
19.5 V
RCA Line:
10.5 V
Dynamic Range
120 dBA
Impedance
XLR Line Outputs:
≤ 100 Ohms (Balanced)
RCA Line Outputs:
≤ 50 Ohms (Unbalanced)
1/4" Headphone Outputs:
< 1 Ohm (Unbalanced)
4.4 mm Headphone Outputs:
≤ 1 Ohm (Balanced)
THD+N
Analog Outputs:
< 0.0015% (32-Ohm Load)
SNR
-120 dBA (Balanced, Unbalanced)
Digital Audio
Sample Rates
Up to 768 kHz (PCM)
22.6 MHz (DSD)
Compatibility
OS Compatibility
Android/iOS
Mobile App Compatible
Yes: Android & iOS
App Name: iFi Nexis
Functionality: Adjust Settings, Firmware Update, Remote Control
Mobile Device Compatibility
No
Power
Power Requirements
AC/DC Power Adapter (Included)
Ground Lift
No
DC Input Power
12 to 15 VDC at 1.5A
AC/DC Power Adapter
100 to 240 VAC (Included)
Power Consumption
13.5 W (Maximum)
5 W (Standby)
Physical
Dimensions
8.4 x 6.2 x 1.6" / 214 x 158 x 41 mm
Weight
2.0 lb / 916.0 g
