Size & weight
Net weight
27.5kg (60.6 lb)
Dimensions
Height: 985 mm (38.8 in) cabinet only
1,020 mm (40.2 in) including plinth
Width: 190 mm (7.5 in) cabinet only
260 mm (10.2 in) including plinth
Depth: 340 mm (13.4 in) cabinet only
368 mm (14.5 in) including grille and terminals
402 mm (15.8 in) including plinth
Technical Details
Drive units
1x ø25mm (1 in) Titanium Dome high-frequency
1x ø150mm (6 in) Continuum cone FST midrange
2x ø165mm (6.5 in) Paper bass cone
Frequency range
-6dB 29Hz - 33kHz
Harmonic distortion
2nd and 3rd harmonics (90dB, 1m on axis)
<1% 100Hz - 22kHz
<0.5% 350Hz - 12kHz
Nominal impedance
8Ω (minimum 3.0Ω)
Recommended amplifier power
30W - 200W into 8Ω on unclipped programme
Technical features
Decoupled Double Dome Titanium tweeter
Continuum™ cone FST™ midrange
Paper bass cones
Flowport™
Description
3-way vented-box system
Max recommended cable impedance
0.1Ω
Frequency response (+/-3dB from reference axis)
46Hz - 28kHz ±3dB
Sensitivity (on axis at 2.83Vrms at 1m)
90dB
