• Net weight9.58kg (21.1 lb)
• DimensionsHeight: 345mm (13.6 in) cabinet only
  413mm (16.3 in) including tweeter
  Width: 192mm (7.6 in) cabinet only
  Depth: 297mm (11.7 in) cabinet only
  337mm (13.3 in) including grille and terminals

Technical Details

• Drive units1x ø25mm (1 in) Decoupled Carbon Dome high-frequency
  1x ø165mm (6.5 in) Continuum cone bass / midrange
• Frequency range45Hz and 33kHz
• Frequency response50Hz - 28kHz ±3dB
• Harmonic distortion2nd and 3rd harmonics (90dB, 1m on axis)
  <1% 100Hz - 22kHz
  <0.5% 150Hz - 20kHz
• Nominal impedance8Ω (minimum 3.7Ω)
• Recommended amplifier power30W - 120W into 8Ω on unclipped programme
• Sensitivity88dB spl (2.83Vrms, 1m)
• Technical featuresDecoupled Carbon Dome tweeter
  Solid Body Tweeter-on-Top
  Continuum™ cone bass / midrange
  Flowport™
• Description2-way vented-box system
• Max recommended cable impedance0.1Ω
